Blog #0191: From Letters to Logits

Source: Photo by Markus Spiske on Unsplash

[ED: Part 2 of 4. Character-level tokenization, linear algebra, softmax, and the complete GPT architecture — all in pure Elixir. 5/5 hats.]

Series: Building GPT from Scratch in Elixir

This is Part 2 of a 4-part series:

• Part 1: What If Numbers Could Remember? — Autograd
• Part 2: From Letters to Logits — Tokenization, building blocks, and the GPT architecture (this post)
• Part 3: How Tokens Talk to Each Other — Attention
• Part 4: Learning and Dreaming — Training and generation

A neural network can't read letters. It needs numbers — and a small set of mathematical operations to transform them. This post builds the bricks and assembles the GPT architecture.

Part 1 covered the autograd engine: a Value struct that tracks every computation in a directed acyclic graph, and a backward/1 function that computes gradients by walking that graph in reverse — plus a threaded RNG that guarantees deterministic reproducibility by construction.

Three more things are needed before the model can train:

1. A tokenizer — to convert text into numbers the model can process
2. Math building blocks — dot products, matrix multiplication, softmax, normalization
3. A model — the GPT architecture itself, with all its weight matrices and the forward pass

These map to three modules in MicroGPTEx's dependency chain:

RNG → Value → Tokenizer → Math → Model → ...
              ^^^^^^^^    ^^^^   ^^^^^
              this post covers these three

Tokenization: converting text to numbers

The tokenizer maps characters to integers and back. It's character-level — each unique character in the training data gets its own ID, and a special BOS (beginning-of-sequence) token marks the start and end of each name.

alias Microgptex.Tokenizer

tok = Tokenizer.build(["alice", "bob", "charlie"])

tok.uchars      #=> ["a", "b", "c", "e", "h", "i", "l", "o", "r"]
tok.vocab_size  #=> 10  (9 chars + 1 BOS)
tok.bos         #=> 9   (BOS gets the last ID)

build/1 extracts every unique character, sorts them, assigns sequential IDs, and reserves the last slot for BOS. The result is a struct with two maps — char_to_id for encoding and id_to_char for decoding:

tok.char_to_id  #=> %{"a" => 0, "b" => 1, "c" => 2, ...}
tok.id_to_char  #=> %{0 => "a", 1 => "b", 2 => "c", ...}

Keeping both directions as maps gives O(1) lookup in either direction. This is a useful Elixir pattern whenever you have a fixed, bidirectional mapping — build both maps once and use assertive Map.fetch!/2 access thereafter.

Encoding and the BOS token

Each training document gets wrapped with BOS at both ends:

Tokenizer.encode(tok, "bob")  #=> [9, 1, 7, 1, 9]
#                                  ^  b  o  b  ^
#                                  BOS         BOS

The leading BOS says "start of name." The trailing BOS says "I'm done." The model learns both meanings from the same token — BOS at the start is the prompt, BOS at the end is the target that teaches the model to stop generating.

This encoding defines the model's task. At each position, predict the next token:

Position 0: BOS → b     "After start-of-name, predict 'b'"
Position 1: b   → o     "After 'b', predict 'o'"
Position 2: o   → b     "After 'o', predict 'b'"
Position 3: b   → BOS   "After 'b', predict end-of-name"

Every training example is a sequence of these (input, target) pairs. The model sees the input token and must predict the target. The loss measures how wrong it is.

Why character-level?

Production models use subword tokenizers (BPE, SentencePiece) with 30K-100K tokens. MicroGPTEx uses character-level because the vocabulary is tiny (~27 tokens for lowercase English names), the embedding matrices stay small, and the algorithm is identical — only the vocabulary size changes. No tokenizer training step needed.

Math building blocks

The GPT model is built from a small set of mathematical operations. Each one operates on lists of Value nodes, so gradients flow through everything automatically.

Dot product

The dot product measures similarity between two vectors: sum(w_i * x_i). In attention, it computes how much one position "attends to" another.

alias Microgptex.Math

query = [V.leaf(1.0, :q1), V.leaf(0.0, :q2), V.leaf(1.0, :q3)]
key   = [V.leaf(1.0, :k1), V.leaf(1.0, :k2), V.leaf(0.0, :k3)]

score = Math.dot(query, key)
score.data  #=> 1.0  (1*1 + 0*1 + 1*0)

The implementation is three lines: zip, multiply, sum:

def dot(ws, xs) do
  Enum.zip(ws, xs)
  |> Enum.map(fn {w, x} -> V.mul(w, x) end)
  |> V.sum()
end

Because every V.mul and V.sum builds autograd nodes, gradients flow backward through the dot product for free.

Linear transform

Matrix-vector multiplication is the core operation of every neural network layer. Each row of the weight matrix produces one output element via a dot product:

def linear(x, w) do
  Enum.map(w, fn w_row -> dot(w_row, x) end)
end

That's it. One line. Every projection in the model — embedding lookups, attention Q/K/V, MLP layers, the final output head — is a call to Math.linear/2.

Softmax

Softmax converts a vector of raw scores (logits) into a probability distribution that sums to 1.0. The larger the input, the higher its probability:

logits = [V.leaf(2.0, :a), V.leaf(5.0, :b), V.leaf(1.0, :c)]
probs = Math.softmax(logits)

# probs ≈ [0.0420, 0.9362, 0.0218]
# The largest logit (5.0) dominates the distribution

The implementation uses the standard numerical stability trick — subtract the max before exponentiating to prevent overflow:

def softmax(logits) do
  max_val = logits |> Enum.map(& &1.data) |> Enum.max()
  exps = Enum.map(logits, fn v -> V.exp(V.sub(v, max_val)) end)
  total = V.sum(exps)
  Enum.map(exps, &V.divide(&1, total))
end

A subtle detail: max_val is extracted as a raw float (.data), not as a Value node. This means the subtraction is treated as a constant shift during differentiation. That's correct — shifting all logits by a constant doesn't change the softmax output or its gradient. But it prevents exp from blowing up on large values.

Temperature

Temperature is a scaling trick applied before softmax. Divide the logits by a temperature value:

• Low temperature (e.g. 0.1) — the distribution becomes sharper, peaking hard on the most likely token. The model becomes confident and repetitive.
• High temperature (e.g. 2.0) — the distribution flattens, giving lower-probability tokens more of a chance. The model becomes creative and noisy.
• Temperature = 1.0 — the unmodified distribution, as the model learned it.

logits = [2.0, 5.0, 1.0]

temp=0.1: [0.0000, 1.0000, 0.0000]  ← almost deterministic
temp=0.5: [0.0003, 0.9994, 0.0003]  ← very confident
temp=1.0: [0.0420, 0.9362, 0.0218]  ← the learned distribution
temp=2.0: [0.1402, 0.6439, 0.2160]  ← more spread out

Temperature doesn't change the model — it changes how the model's output is interpreted. The model always produces the same logits for the same input; temperature just reshapes the probability distribution before sampling.

RMSNorm

RMSNorm normalises a vector so its root-mean-square is approximately 1.0:

rmsnorm(x) = x / sqrt(mean(x^2) + eps)

This prevents activations from growing or shrinking uncontrollably during the forward pass. Without normalization, deep networks tend to have exploding or vanishing activations, which makes training unstable.

def rmsnorm(x, eps \\ 1.0e-5) do
  ms = x |> Enum.map(fn xi -> V.mul(xi, xi) end) |> V.mean()
  scale = V.pow(V.add(ms, eps), -0.5)
  Enum.map(x, fn xi -> V.mul(xi, scale) end)
end

RMSNorm is a simpler alternative to LayerNorm — it skips the mean-centering step. Modern architectures like LLaMA use it because it's cheaper to compute and works just as well in practice.

The complete toolkit

Six functions are all the math needed for a GPT:

Each one produces Value nodes, so the autograd engine from Part 1 handles all gradient computation automatically.

The GPT model

Now all the pieces are in place to build the actual model. A GPT is a stack of weight matrices organized into a specific architecture. Model.init/1 creates them all with random values:

alias Microgptex.{Model, RNG}

cfg = %{
  n_layer: 1,      # transformer layers
  n_embd: 8,       # embedding dimension
  block_size: 8,    # max sequence length
  n_head: 2,        # attention heads (head_dim = 8/2 = 4)
  vocab_size: 5,    # tokens in vocabulary
  std: 0.08,        # weight initialization std dev
  seed: 42
}

{model, _rng} = Model.init(cfg)

The model state is a nested map of Value leaf nodes — the learnable parameters. Here's what's inside:

Where the parameters live

Token embeddings (wte):     vocab_size × n_embd     =  5 × 8  =   40
Position embeddings (wpe):  block_size × n_embd     =  8 × 8  =   64
Language model head:        vocab_size × n_embd     =  5 × 8  =   40

Per transformer layer:
  Attention Q projection:   n_embd × n_embd         =  8 × 8  =   64
  Attention K projection:   n_embd × n_embd         =  8 × 8  =   64
  Attention V projection:   n_embd × n_embd         =  8 × 8  =   64
  Attention O projection:   n_embd × n_embd         =  8 × 8  =   64
  MLP fc1:                  (4 × n_embd) × n_embd   = 32 × 8  =  256
  MLP fc2:                  n_embd × (4 × n_embd)   =  8 × 32 =  256

Total: 40 + 64 + 40 + 64*4 + 256 + 256 = 912 parameters

Every one of these 912 parameters is a Value leaf node with a stable {tag, row, col} ID:

# A weight in the token embedding matrix, row 2, column 5:
%Value{data: 0.0312, id: {"wte", 2, 5}, children: [], local_grads: []}

Aside: why strings and not atoms for the tags? The per-layer tags are built with string interpolation — "layer#{li}.attn_wq" — because the layer index is a runtime integer. Dynamically creating atoms is generally discouraged in Elixir since the atom table is never garbage collected. With only 1-2 layers it wouldn't matter in practice, but strings are the safer habit. Since the IDs are only used as map keys for equality comparison, there's no functional difference.

These stable IDs are critical. The training loop needs to:

1. Flatten all parameters into a list (Model.params/1)
2. Run the forward pass and compute loss
3. Call V.backward(loss) to get a %{id => gradient} map
4. Feed the gradients to the Adam optimizer (Adam.step/5)
5. Get back a %{id => new_value} map of updated parameter values
6. Walk the model tree and apply updates (Model.update_params/2)

The same {"wte", 2, 5} ID links a parameter through flatten → gradient → optimizer → update → back into the model. Without stable IDs, the optimizer's momentum and velocity buffers (which track per-parameter statistics across training steps) wouldn't know which parameter is which.

In Python, this linking happens implicitly through shared mutable object references — the optimizer holds a reference to the same object as the model, so optimizer.step() can mutate it directly. In Elixir, the linking is explicit through ID-keyed maps.

The forward pass

The forward pass takes a single token and produces a prediction. Given (token_id, position_id), it returns logits — a score for each possible next token:

kv_cache = Model.empty_kv_cache(model)

{logits, kv_cache} = Model.gpt(model, 0, 0, kv_cache)
# logits is a list of 5 Values (one per vocab token)

Here's what happens inside Model.gpt/4:

def gpt(model, token_id, pos_id, kv_cache) do
  %{wte: wte, wpe: wpe, lm_head: lm_head, layers: layers} = model.state

  # 1. Look up embeddings and normalise
  x =
    Enum.at(wte, token_id)
    |> Math.add_vec(Enum.at(wpe, pos_id))
    |> Math.rmsnorm()

  # 2. Pass through transformer blocks
  {x, kv_cache} =
    Enum.reduce(0..(model.n_layer - 1), {x, kv_cache}, fn li, {x, kv_cache} ->
      layer = Map.fetch!(layers, li)
      {x, kv_cache} = attn_block(model, x, li, layer, kv_cache)
      x = mlp_block(x, layer)
      {x, kv_cache}
    end)

  # 3. Project to vocabulary
  logits = Math.linear(x, lm_head)
  {logits, kv_cache}
end

Three steps:

1. Embed: look up the token's embedding vector from wte, add the position embedding from wpe, normalise with RMSNorm. This gives the model two pieces of information — what token this is and where it is in the sequence.

2. Transform: pass through each transformer block (attention + MLP). Each block refines the representation, incorporating information from previous tokens via the attention mechanism and the KV cache.

3. Project: multiply by lm_head to produce a score for each token in the vocabulary. These scores (logits) become probabilities after softmax.

An untrained model outputs near-random logits — it has no idea what comes next. After training, the logits encode which tokens are likely to follow. The token with the highest logit is the model's best guess; softmax turns these into a probability distribution for sampling.

The kv_cache flows in and out of the forward pass, carrying attention state from previous positions. Part 3 covers how this works in detail.

Lists as vectors

One thing might look unusual to Elixir developers: the model uses plain lists as vectors and lists-of-lists as matrices. There's no Nx, no tensors, no special numeric types.

# A vector is [%Value{}, %Value{}, ...]
# A matrix is [[%Value{}, ...], [%Value{}, ...], ...]

This means Enum.at/2 for indexed access — O(n), not O(1). For production work, that's unacceptable. But for this pedagogical codebase, the dimensions are tiny: vocabulary ~27, embedding ~16, block size ~16. The O(n) cost is negligible.

The upside is transparency. The data structures are plain Elixir — no special types to learn, no opaque tensor operations, no shape-mismatch errors. You can IO.inspect any intermediate value and see exactly what's inside. Every operation is a simple Enum.map or Enum.zip that you can read and trace.

For real work, use Nx + EXLA. For understanding, use lists.

Three more modules

With tokenization, math, and the model in place, the module count is up to five:

• Tokenizer — character-level encoding with BOS framing and O(1) bidirectional lookup maps
• Math — six operations (dot, linear, softmax, rmsnorm, add_vec, relu_vec) that produce Value nodes for automatic gradient computation
• Model — the GPT architecture: embeddings, transformer blocks, language model head, stable {tag, row, col} parameter IDs, and a forward pass that processes one token at a time

The model can do a forward pass — turn a token ID into logits over the vocabulary. But the most interesting part was glossed over: what happens inside the transformer block? How does the model "look at" previous tokens to decide what comes next?

Up next

Part 3: "How Tokens Talk to Each Other" opens up the transformer block and explains multi-head self-attention — the mechanism that lets each token attend to all previous tokens. Query/key/value projections, scaled dot-product attention, the KV cache, and residual connections. It's simpler than it sounds.
